铜河精密模具（常州）有限公司

Tonghe Precision Mold Co., Ltd

展位号：2564

展出产品：步进电机_42定子铁芯、

模具样品、步进电机_57定子圆形铁芯等

联系方式：0519-88612298

网址：www.tongheltd.com

邮箱：tonny@tongheltd.com

公司简介

       铜河精密模具（常州）有限公司是一家专注于各类电机冲片级进模设计、制造、生产、销售与服务的实力型模具制造企业，擅长大回转类铁芯级进模具解决方案，我们在步进电机铁芯级进模具类有丰富的设计及开模经验，为外资、中资、民营企业开发多套铁芯级进模具，能为客户提供高品质、高效益、高寿命的模具开发与制造，提供最佳的产品和模具方案。公司位于常州市武进区人民路，紧靠沪武高速、312国道与常州环城高架，交通便利。

       我们的步进电机大回转铁芯级进模具在国内有较高的知名度，国内合作伙伴遍布全国各地，并收到越来越多的国外客户订单，产品出口美国、日本、韩国、意大利、印度、巴西等国家，受到国内外客户高度肯定。

       我们专业设计生产各类马达定转子级进模，模具主要零件制造精度达2um，步距精度5um以内，总寿命在1.5亿冲次以上，并具有自动冲压、叠铆、冲台阶孔、扭槽、回转等功能。可根据客户要求，按单列或多列排样开模，开模周期速度远超同行。

Tonghe Precision Mold Co., Ltd. is a powerful manufacturer specializing in the design, manufacturing, production, sales and service of progressive tooling for all kinds of motor laminations. It manufactures capable tooling with auto-stacked, auto-skewed and rotary (indexing) rotors and stators in processed cores or loose laminations, and has rich experience especially in design and manufacturing of progressive tooling for stepper motor cores. Our customers include overseas and Chinese funded enterprises. Providing high quality, high efficiency and high lifetime progressive tooling is our mission, and our commitment to our customers. The company is located in Wujin District, Changzhou City, easily accessible as it is close to the Shanghai-Wuhan Expressway, the 312 National Highway and the Changzhou Ring Elevated Highway.

Our servo motor hinge core progressive tooling are well-known in China. We have domestic partners all over the country, and are receiving more and more orders from foreign customers. Our products are exported to the United States, Japan, South Korea, Italy, India, Brazil, to name just a few, and are highly recognized by both domestic and foreign customers.

We specialize in the design and production of progressive tooling for all kinds of motor stator and rotors. The manufacturing accuracy of the main parts of the tooling reaches as high as 2 μm and the pitch precision can be controlled within 5 μm. The tool life attains to above 150 million strokes. Our tooling realize multiple functions such as auto pressure charging, auto stacking, step holes punching, auto skewing, and auto rotation. We can also make single-row or multi-row tooling according to customer requirement. The fast tooling production lead time is way beyond our peers.

部分展品

1、模具样品

产品介绍

模具主要零件制造精度达2um，步距精度5um以内，总寿命在1.5亿冲次以上，具有自动冲压、叠铆、冲台阶孔、扭槽、回转等功能。

The manufacturing accuracy of the main parts of the tooling reaches as high as 2 μm and the pitch precision can be controlled within 5μm. The tool life attains to above 150 million strokes. Our tooling realize multiple functions such as auto pressure charging, auto stacking, step holes punching, auto skewing, and auto rotation.

2、步进电机_42定子铁芯

产品介绍

产品外形42.2×42.2-L43

定子90°回转

垂直度0.08，倾斜度0.1

Product shape 42.2 × 42.2-L43.

90° rotation of stator.

The perpendicularity is 0.08 and the inclination is 0.1.

3、步进电机_57定子圆形铁芯

产品介绍

产品外形56.2×56.2-L89

定子90°回转

倾斜度0.15，平面度0.15

Product shape 56.2 × 56.2-L89.

90° rotation of stator.

The inclination is 0.15 and the flatness is 0.15.
